Name: Ebara - 2GPE EVMSG3 12N5/1,1 ESPM - Part Number: 2GPE EVMSG3 12N5/1,1 ESPM
Brand: Waterials
SKU: 2GPE EVMSG3 12N5/1,1 ESPM
Availability: InStock

Part Number: 2GPE EVMSG3 12N5/1,1 ESPM

1	Pump type	Booster Set	Fluid	Water
2	Number of pumps	2	Liquid temperature °C	20
3	Flow m³/h		Kin. viscosity cSt	1.005
4	Head m		Vapour pressure kPa	2.34
5	Geodetic head m		PH value
6	Inlet pressure kPa	0	Density kg/m³	998.3
7	Available system NPSH	Ask our technical department.	Solids Weight %	0
8	Ambient temperature °C	20	Installation height m	100

Booster Set
9	Booster set name	2GPE EVMSG3 12N5/1,1 ESPM	Frequency Hz	None	50
10	Design	Booster Set		None
11	Manufacturer	EBARA	Impeller Dia.	Max. mm	79
12	Speed rpm	2850	None	Designed mm	79
13	No. of Stage	12	None	Min. mm	79
14	Connection Suction side	G 1 1/2 PN16	Flow	Operating m³/h
15	Connection Discharge side	G 1 1/2 PN16	None	Max- m³/h	4.5
16	Max Working Pressure kPa	1600	None	Min- m³/h	1.2
17	Shut-off head kPa	836.81	Head	Operating m
18	Total weight kg	See the table of “Dimensions”.	None	– (Qmax.) m	46.9
19	Shaft power kW		None	– (Qmin.) m	81.5
20			Max. Shaft Power at max. impeller kW	None	1.06
21	Required NPSH m		Efficiency %	None

Materials
22	Frame	Galvanized steel	Shaft	AISI 304
23	Manifold	AISI 304	O-ring	EPDM
24	Check valve	Brass / NBR
25	Ball / Butterfly valve	Brass / PTFE
26	Impeller	AISI 304
27	Casing	Cast iron

Motor
28	Manufacturer	ETM	Insulation class	F
29	Type	TEFC_EVMS3 12/1.1_230_Three Phase	Phases	3~
30	Specific design	IE3 / 50 Hz / Pole pairs 1	Frame size	80
31	Rated power kW	1.1	Weight; motor kg	10
32	Number of poles	2	Electric voltage V	230
33	Speed rpm	2830	Electric current A	4.3
34	Degree of protection	IP 55
