| Product name | BM 32-3 NBR |
| Product No | 93205133 |
| EAN number | 5715123591636 |
| Rated flow | 32 m³/h |
| Rated head | 21 m |
| Stages | 3 |
| Curve tolerance | ISO9906:2012 3B |
| Model | E |
| Pump | Stainless steel |
| Impeller | Stainless steel |
| Motor | Stainless steel |
| Code for rubber | NBR |
| Sleeve | Stainless steel |
| Maximum operating pressure | 82.7 bar |
| Maximum permissible inlet pressure | 50 bar |
| Maximum outlet pressure | 82 bar |
| Pipe connection standard | PJE |
| Pipe connection | 89 mm |
| Pumped liquid | Water |
| Maximum liquid temperature | 40 °C |
| Selected liquid temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Rated power – P2 | 3 kW |
| Mains frequency | 50 Hz |
| Rated voltage | 3 x 380-400-415 V |
| Rated current | 7.7-7.9-8.1 A |
| Starting current | 430-450-460 % |
| Cos phi – power factor | 0.86-0.81-0.77 |
| Method of start | Direct-on-line (DOL) |
| Enclosure class (IEC 34-5) | IP66 |
| Thermal protection | External |
| Built-in temp. transmitter | Yes |
| Motor No | 7C193508 |
| Minimum efficiency index, MEI ≥ | 0.50 |
| Net weight | 48 kg |
| Gross weight | 68.2 kg |
| Shipping volume | 0.26 m³ |
BM 32-3 NBR
