Lowara CA2006/33/D Centrifugal Pump – Technical Specifications
Product Overview
The Lowara CA2006/33/D is a twin-impeller centrifugal electric pump engineered for high-performance water supply, pressure boosting, and fluid transfer applications. Designed to meet the ISO 9906:2012 Grade 3B performance standards, this monobloc pump is built with high-quality stainless steel components for long-term durability and resistance to corrosion.
Hydraulic Performance
-
Maximum Head: 205 ft
-
Maximum Flow Rate: 55 US g.p.m.
-
Duty Point Flow: 0 US g.p.m.
-
Duty Point Head: 0 ft
-
Maximum Shaft Power: 2.61 hp
Motor Specifications
-
Rated Power (P2): 4.0231 hp
-
Motor Speed: 3480 rpm
-
Rated Voltage: 220 V
-
Rated Current: 10.7 A
-
Frequency / Phase: 60 Hz / 3-phase
-
Insulation Class: F
-
Protection Class: IP55
-
Permitted Voltage Tolerance: ±10%
-
Pump Speed: 3500 rpm
Materials of Construction
-
Pump Body: Stainless Steel AISI 304
-
Impeller: Stainless Steel AISI 304
-
Diffuser Cover: Stainless Steel AISI 304
-
Suction Flange: Stainless Steel AISI 304
Mechanical Seal Components
-
Fixed Assembly: B-Carbon
-
Rotating Assembly: V-Ceramic Alumina
-
Elastomers: E-EPDM
-
Springs: G-AISI 316
-
Other Parts: F-AISI 304
Operating Conditions
-
Operating Medium: 100% Water
-
Reference Conditions:
-
Temperature: 39.2°F
-
Density: 62.4 lb/ft³
-
Kinematic Viscosity: 1.69E-5 ft²/s
-
-
Installation Type: Monobloc
Pump Dimensions (in inches)
-
D: 7 1/64
-
H: 9 1/2
-
L: 17 13/16
-
L1: 5 11/16
-
M: 4 15/16
-
M1: 5 7/8
-
N: 5 1/2
-
N1: 6 11/16
-
S: 1/2
-
S1: 3/8
-
W: 3 7/8
-
Inlet (DNA): Rp 1½
-
Outlet (DNM): Rp 1
General Information
-
Model: CA2006/33/D
-
Weight: 57.319 lb
-
Compliance Standard: ISO 9906:2012 – Grade 3B
