Lowara CAM120/33/C Twin-Impeller Centrifugal Pump – Technical Specifications
Product Overview
The Lowara CAM120/33/C is a twin-impeller centrifugal electric pump ideal for water transfer, pressure boosting, and clean water circulation. Designed for high efficiency and durability, this monobloc pump is made from AISI 304 stainless steel and complies with ISO 9906:2012 – Grade 3B standards.
Hydraulic Performance
-
Maximum Head: 44.9 meters
-
Maximum Flow Rate: 8.0 m³/h
-
Duty Point Flow: 0 m³/h
-
Duty Point Head: 0 meters
-
Maximum Shaft Power: 1.28 kW
Motor Specifications
-
Rated Motor Power (P2): 1.5 kW
-
Nominal Speed: 2890 rpm
-
Rated Voltage: 221 V
-
Rated Current: 8.41 A
-
Frequency / Phase: 50 Hz / Single-phase (1~)
-
Insulation Class: F
-
Protection Class: IP55
-
Permitted Voltage Tolerance: ±10%
-
Design Speed: 2900 rpm
Materials of Construction
-
Pump Body: AISI 304 Stainless Steel
-
Impeller: AISI 304 Stainless Steel
-
Diffuser Cover: AISI 304 Stainless Steel
-
Suction Flange: AISI 304 Stainless Steel
Mechanical Seal Details
-
Fixed Assembly: B-Carbon
-
Rotating Assembly: V-Ceramic Alumina
-
Elastomers: E-EPDM
-
Springs: G-AISI 316
-
Other Parts: F-AISI 304
Operating Conditions
-
Operating Medium: Clean water
-
Reference Conditions:
-
Temperature: 4°C
-
Density: 1000 kg/m³
-
Kinematic Viscosity: 1.57 mm²/s
-
-
Installation Type: Monobloc
Pump Dimensions (mm)
-
D: 174
-
H: 265
-
L: 454
-
L1: 58
-
M: 125
-
M1: 155
-
N: 140
-
N1: 170
-
S: 13
-
S1: 10
-
W: 98
-
Inlet (DNA): Rp 1¼
-
Outlet (DNM): Rp 1
General Information
-
Model: CAM120/33/C
-
Weight: 27.5 kg
-
Compliance: ISO 9906:2012 – Grade 3B
