Lowara CAM70/44/C Twin-Impeller Centrifugal Pump – Technical Specifications
Product Overview
The Lowara CAM70/44/C is a high-efficiency twin-impeller centrifugal electric pump, ideal for clean water transfer, pressure boosting, and residential or light commercial applications. Manufactured from AISI 304 stainless steel, this monobloc design complies with ISO 9906:2012 – Grade 3B standards for performance and reliability.
Hydraulic Performance
-
Maximum Head: 51.8 meters
-
Maximum Flow Rate: 4.5 m³/h
-
Hydraulic Duty Point Flow: 0 m³/h
-
Hydraulic Duty Point Head: 0 meters
-
Maximum Shaft Power: 1.18 kW
Motor Specifications
-
Rated Power (P2): 1.1 kW
-
Nominal Speed: 2860 rpm
-
Rated Voltage: 221 V
-
Rated Current: 6.26 A
-
Frequency / Phase: 50 Hz / Single-phase (1~)
-
Insulation Class: F
-
Protection Class: IP55
-
Permitted Voltage Tolerance: ±10%
-
Design Pump Speed: 2900 rpm
Materials of Construction
-
Pump Body: AISI 304 Stainless Steel
-
Impeller: AISI 304 Stainless Steel
-
Diffuser Cover: AISI 304 Stainless Steel
-
Suction Flange: AISI 304 Stainless Steel
Mechanical Seal Components
-
Fixed Assembly: B-Carbon
-
Rotating Assembly: V-Ceramic Alumina
-
Elastomers: E-EPDM
-
Springs: G-AISI 316
-
Other Components: F-AISI 304
Operating Conditions
-
Working Medium: 100% Clean Water
-
Reference Conditions:
-
Temperature: 4°C
-
Density: 1000 kg/m³
-
Viscosity: 1.57 mm²/s
-
-
Installation Type: Monobloc
Pump Dimensions (mm)
-
D: 156
-
H: 242
-
L: 420
-
L1: 69
-
M: 100
-
M1: 125
-
N: 125
-
N1: 153
-
S: 12
-
S1: 9
-
W: 76
-
Inlet (DNA): Rp 1¼
-
Outlet (DNM): Rp 1
General Information
-
Model: CAM70/44/C
-
Weight: 18.5 kg
-
Compliance: ISO 9906:2012 – Grade 3B
