Ready for connection and fully submersible single pump lifting unit for pumping sewage containing faeces.
Gas- and watertight collection tank with sloped floor at an angle and an inspection opening with transparent cover.Freely selectable inlets within the marked areas.Level measurement performed with an analogue output signal 4 … 20 mA.Discharge port attached with a non-return valve including an inspection opening.
Surface-cooled motor with thermal motor monitoring.
Pre-installed switchgear for automatic operation:
– Collective fault signal with potential-free contact
– Integrated and mains-independent alarm
– Adjustable follow-up time
– 1.5 m connection cable with attached plug
Scope of delivery
– Lifting unit with switchgear and connection cable with plug
– Flange connector DN 80 (90 mm)/DN 100 (110 mm)
– Collar DN 100 (110 mm) for discharge connection
– HT double socket DN 65 (75 mm) for ventilation connection
– HT double socket DN 40 (50 mm) for drain connection
– Inlet set with hole saw 124 mm (5 in) and seal DN 100 (110 mm)
– Floor fixation set
– Noise insulation mat
– 9 V rechargeable battery
– Installation and operating instructions
Operating Data
Fluid media: Water 100 %
Fluid temperature: 20.00 °C
Requested flow:
Requested head:
Approved field of application
Fluid temperature: 3…40 °C
Max. fluid temperature, for short periods up to 5 min.: {P.temperature_fluid_short_term_5min;;;1}
Ambient temperature: 3…40 °C
Maximum operating pressure: 4 bar
Max. permissible pressure in the pressure pipe: 1,500 kPa
Product data
Gross volume of the tank: 99 l
Useable volume at 180 mm inlet height: 50 l
Useable volume at 250 mm inlet height: 63 l
Useable volume at 315 mm inlet height: 74 l
Sound-pressure level: 70 dB
Operating mode (non-immersed): S3-10%
Height: 571 mm
Length: 700 mm
Width: 600 mm
Diagonal dimension: 850 mm
Free ball passage of the hydraulics: 44 mm
Motor data
Mains connection: 3~400V/50 Hz
Voltage tolerance: +-10 %
Rated power: 1.5 kW
Rated speed: 2,850 1/min
Rated current: 3.6 A
Starting current – direct :
Insulation class: F
Protection class motor: IP68
Activation type: Direct On Line (DOL)
Max. switching frequency: 60 1/h
Operating mode per pump:
Motor protection: Bimetall
Cable
Connection cable length: 4 m
Cable type: H07RN-F
Cable cross-section: 6G1
Mains plug: CEE 16A, 3P+N+PE, 6h
Materials
Tank: PE
Pump housing: PP-GF30
Impeller: PP-GF30
Shaft: 1.4401
Gasket material: NBR
Motor housing: 1.4301
Installation dimensions
Pipe connection on the suction side: DN 110 (110 mm), PN 0,5
Pipe connection on the discharge side: DN 80, PN 10
Connection venting: DN 75 (75 mm)
Ordering information
Brand: Wilo
Product description: DrainLift SANI-M.16T/1
Net weight, approx.: 37 kg
Article number: 2549905
