| Operating Data | |
|---|---|
| Operating speed | 2900 rpm Stages 1 Min. mm 113 |
| Head H(Q=0) | 18 at |
| Flow Max | m³/h 29.2 |
| Flow Min | m³/h 7.5 |
| Total weight | kg 34.0 NPSH 3% m |
| Materials | |
| Impeller | Stainless steel / AISI 304 |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 1.5 kW Rated current 5.49 A |
| Rated voltage | 230 V |
| Degree of protection | IP55 |
