| Operating Data | |
|---|---|
| Operating speed | 1750 rpm Stages 1 Min. inch 5 7/8 |
| Head H(Q=0) | 46 at |
| Flow Max | US g.p.m. 96.9 |
| Flow Min | US g.p.m. 26.4 |
| Total weight | lb 90.4 NPSH 3% ft |
| Materials | |
| Impeller | Stainless steel / AISI 304 |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 1.4751 hp Rated current 4.61 A |
| Rated voltage | 220 V |
| Degree of protection | IP55 |
