| Operating Data | |
|---|---|
| Operating speed | 1450 rpm Stages 1 Min. mm 130 |
| Head H(Q=0) | 12 at |
| Flow Max | m³/h 93 |
| Flow Min | m³/h 18 |
| Total weight | kg 78.0 NPSH 3% m |
| Materials | |
| Impeller | Cast iron / ASTM Class 30 |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 2.2 kW Rated current 8.04 A |
| Rated voltage | 230 V |
| Degree of protection | IP55 |
