| Operating Data | |
|---|---|
| Operating speed | 1470 rpm Stages 1 Min. mm 276 |
| Head H(Q=0) | 31 at |
| Flow Max | m³/h 300 |
| Flow Min | m³/h 24 |
| Total weight | kg 276.8 NPSH 3% m |
| Materials | |
| Impeller | Cast iron, 0.6020 Single mechanical seal, without shaft sleeve |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 18.5 kW Rated current 36 A |
| Rated voltage | 400 V |
| Degree of protection | IP55 |
