| Operating Data | |
|---|---|
| Operating speed | 970 rpm Stages 1 Min. mm 230 |
| Head H(Q=0) | 8.9 at |
| Flow Max | m³/h 226.7 |
| Flow Min | m³/h 27 |
| Total weight | kg 196.0 NPSH 3% m |
| Materials | |
| Impeller | Cast iron, 0.6020 Single mechanical seal, without shaft sleeve |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 4 kW Rated current 9.2 A |
| Rated voltage | 400 V |
| Degree of protection | IP55 |
