| Operating Data | |
|---|---|
| Operating speed | 975 rpm Stages 1 Min. mm 267 |
| Head H(Q=0) | 14 at |
| Flow Max | m³/h 815.8 |
| Flow Min | m³/h 179.1 |
| Total weight | kg 614.8 NPSH 3% m |
| Materials | |
| Impeller | Cast Iron, EN 1561 – GJL-200, ASTM Class 30 eMG12 – Ø48mm BQ7EGG-WA |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 15 kW Rated current 30.6 A Frame size 110 |
| Rated voltage | 400 V Spacer length mm 4 |
| Degree of protection | IP55 Coupling protection GR.COUPLGUARD ES42-230-16 A4 1.7 kg |
