| Operating Data | |
|---|---|
| Operating speed | 2900 rpm Stages 1 Min. mm 199 |
| Head H(Q=0) | 100 at |
| Flow Max | m³/h 66 |
| Flow Min | m³/h 24 |
| Total weight | kg 233.4 NPSH 3% m |
| Materials | |
| Impeller | Fabricated Stainless Steel |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 22 kW Rated current 37.9 A Frame size 110 |
| Rated voltage | 400 V Spacer length mm 3 |
| Degree of protection | IP55 Coupling protection COUPLGUARD 175x152PNTD 0.33 kg |
