| Operating Data | |
|---|---|
| Operating speed | 1450 rpm Stages 1 Min. mm 144 |
| Head H(Q=0) | 7.6 at |
| Flow Max | m³/h 58 |
| Flow Min | m³/h 13 |
| Total weight | kg 75.1 NPSH 3% m |
| Materials | |
| Impeller | Fabricated Stainless Steel |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 1.1 kW Rated current 2.65 A Frame size 68 |
| Rated voltage | 400 V Spacer length mm 3 |
| Degree of protection | IP55 Coupling protection COUPLGUARD 160x102PNTD 0.22 kg |
