| Operating Data | |
|---|---|
| Operating speed | 2900 rpm Stages 1 Min. mm 165 |
| Head H(Q=0) | 70 at |
| Flow Max | m³/h 189 |
| Flow Min | m³/h 38 |
| Total weight | kg 325.0 NPSH 3% m |
| Materials | |
| Impeller | Cast Iron |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 30 kW Rated current 52.2 A Frame size 125 |
| Rated voltage | 400 V Spacer length mm 3 |
| Degree of protection | IP55 Coupling protection COUPLGUARD 175x152PNTD 0.33 kg |
