| Operating Data | |
|---|---|
| Operating speed | 1765 rpm Stages 1 Min. inch 10 1/4 |
| Head H(Q=0) | 180 at |
| Flow Max | US g.p.m. 369.8 |
| Flow Min | US g.p.m. 52.8 |
| Total weight | lb 471.8 NPSH 3% ft |
| Materials | |
| Impeller | Cast Iron, EN 1561 – GJL-200, ASTM Class 30 eMG12 – Ø38mm BQ7EGG-WA |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 20.115 hp Rated current 51.8 A |
| Rated voltage | 220 V |
| Degree of protection | IP55 |
