| Operating Data | |
|---|---|
| Operating speed | 1750 rpm Stages 1 Min. inch 8 7/16 |
| Head H(Q=0) | 110 at |
| Flow Max | US g.p.m. 682.4 |
| Flow Min | US g.p.m. 178.3 |
| Total weight | lb 443.1 NPSH 3% ft |
| Materials | |
| Impeller | Cast Iron |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 20.115 hp Rated current 29.9 A |
| Rated voltage | 380 V |
| Degree of protection | IP55 |
