| Operating Data | |
|---|---|
| Operating speed | 2880 rpm Stages 1 Min. mm 158 |
| Head H(Q=0) | 33 at |
| Flow Max | m³/h 83.4 |
| Flow Min | m³/h 35.8 |
| Total weight | kg 52.0 NPSH 3% m |
| Materials | |
| Impeller | Stainless steel / AISI 316L Uniten 3K VBVGG |
| Rotating ring | Ceramic |
| Stationary ring | Carbon graphite resin impregnated |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 5.5 kW Rated current 10.4 A |
| Rated voltage | 400 V |
| Degree of protection | IP55 |
