| Operating Data | |
|---|---|
| Operating speed | 3530 rpm Stages 1 Min. inch 6 1/4 |
| Head H(Q=0) | 170 at |
| Flow Max | US g.p.m. 346.4 |
| Flow Min | US g.p.m. 159.9 |
| Total weight | lb 194.0 NPSH 3% ft |
| Materials | |
| Impeller | Stainless steel / AISI 316L Uniten 3K VBVGG |
| Rotating ring | Ceramic |
| Stationary ring | Carbon graphite resin impregnated |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 14.751 hp Rated current 35.7 A |
| Rated voltage | 220 V |
| Degree of protection | IP55 |
