| Operating Data | |
|---|---|
| Operating speed | 3500 rpm Stages 1 Min. inch 6 |
| Head H(Q=0) | 140 at |
| Flow Max | US g.p.m. 198.1 |
| Flow Min | US g.p.m. 79.3 |
| Total weight | lb 271.2 NPSH 3% ft |
| Materials | |
| Impeller | Stainless steel / AISI 316L Uniten 3K VBVGG |
| Rotating ring | Ceramic |
| Stationary ring | Carbon graphite resin impregnated |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 7.3756 hp Rated current 18.9 A Frame size Not applicable |
| Rated voltage | 220 V Spacer length inch Not applicable |
| Degree of protection | IP55 Coupling protection Not applicable |
