| Operating Data | |
|---|---|
| Operating speed | 1750 rpm Stages 1 Min. inch 8 1/16 |
| Head H(Q=0) | 75 at |
| Flow Max | US g.p.m. 317 |
| Flow Min | US g.p.m. 132.1 |
| Total weight | lb 392.4 NPSH 3% ft |
| Materials | |
| Impeller | Stainless steel / ASTM CF8M Uniten 3K VBVGG |
| Rotating ring | Ceramic |
| Stationary ring | Carbon graphite resin impregnated |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 5.3641 hp Rated current 8.52 A Frame size Not applicable |
| Rated voltage | 380 V Spacer length inch Not applicable |
| Degree of protection | IP55 Coupling protection Not applicable |
