| Operating Data | |
|---|---|
| Operating speed | 1450 rpm Stages 1 Min. mm 169 |
| Head H(Q=0) | 8 at |
| Flow Max | m³/h 102 |
| Flow Min | m³/h 36 |
| Total weight | kg 127.0 NPSH 3% m |
| Materials | |
| Impeller | Stainless steel / ASTM CF8M Uniten 3K VBVGG |
| Rotating ring | Ceramic |
| Stationary ring | Carbon graphite resin impregnated |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 1.5 kW Rated current 3.7 A Frame size Not applicable |
| Rated voltage | 400 V Spacer length mm Not applicable |
| Degree of protection | IP55 Coupling protection Not applicable |
