| Operating Data | |
|---|---|
| Operating speed | 1750 rpm Stages 1 Min. inch 6 7/16 |
| Head H(Q=0) | 44 at |
| Flow Max | US g.p.m. 264.2 |
| Flow Min | US g.p.m. 118.9 |
| Total weight | lb 119.0 NPSH 3% ft |
| Materials | |
| Impeller | Stainless steel / ASTM CF8M Uniten 3K VBVGG |
| Rotating ring | Ceramic |
| Stationary ring | Carbon graphite resin impregnated |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 2.0115 hp Rated current 6.34 A |
| Rated voltage | 220 V |
| Degree of protection | IP55 |
