Fully submersible sewage lifting unit, ready for connection, with solids separation according to DIN EN 12050-1. Due to the version as a solids separation system, the coarse solids are separated before the pumps and do not come into contact with the pumps. This ensures maximum operational reliability. All-in-one gas-tight and watertight collection reservoir without constructive welded joints, as well as two separately-lockable and externally maintainable solids separation reservoirs. Individual shut-off makes it possible to carry out maintenance work during operation. Pumping is performed by two high-performance submersible sewage pumps in dry well installation that run in alternating operation. The dry well installation of the pumps and their configuration as a redundant double-pump system ensures maximum hygiene, ease of maintenance, and operational reliability. The collection reservoir has rounded edges, the tank bottom is bevelled, the deepest point is located directly below the pump. This prevents deposits and the drying of solids at critical points. Quick connector to the pumps and the inspection opening facilitate maintenance work. Separate blocking of the solids separation reservoir facilitate maintenance while the unit is in operation. Manual backwashing in the collection reservoir reinforces the cleaning effect through additional turbulences and the transparent cover on the distributor box allows easy visual inspection of the unit. Level control is carried out using a level probe.
Scope of delivery
– Submersible pump solids separation system with two dry well installation submersible pumps
– 2x gate valve for solids separation reservoir
– 2x non-return valve on the discharge side in rectangular design
– 2x gate valve on the discharge side
– Consolidation of the pressure outlet line
– 1x level probe
– 1x floor fixation as cross beam
– 2.5 m ventilation and venting hose
– 1x maintenance kit with blind flange
Recommended accessories
– Wilo-Control SC-L-…-FTS switchgear
– Inlet slide valve
– Rinsing kit for supply box
Operating Data
Fluid media: Water 100 %
Fluid temperature: 20.00 °C
Requested flow:
Requested head:
For Wilo pumps:
Approved field of application
Fluid temperature: 3…40 °C
Max. fluid temperature, for short periods up to 3 min.: 40 °C
Max. fluid temperature, for short periods up to 30 min.: {P.temperature_fluid_short_term_30min;;;1}
Ambient temperature: 3…40 °C
Maximum operating pressure: 1.76 bar
Max. permissible pressure in the pressure pipe: 600 kPa
Product data
Gross volume of the tank: 1,200 l
Switching volume: 900 l
Operating mode (non-immersed): S1
Height: 1,960 mm
Length: 1,830 mm
Width: 1,760 mm
Diagonal dimension: 2,000 mm
Motor data
Mains connection: 3~400V/50 Hz
Voltage tolerance: +-10 %
Rated power: 4 kW
Rated speed: 1,450 1/min
Rated current: 9.5 A
Insulation class: H
Protection class motor: IP68
Activation type: Direct On Line (DOL)
Max. switching frequency: 15 1/h
Motor protection: Bimetall
Cable
Connection cable length: 20 m
Cable type: H07RN-F
Cable cross-section: 7G1,5
Mains plug: No
Type of connection cable: Non-detachable
Materials
Tank: PE
Pump housing: 5.1301/EN-GJL-250
Impeller: EN-GJS-500-7
Shaft: 1.4021
Gasket material: FKM
Motor housing: 5.1301/EN-GJL-250
Installation dimensions
Pipe connection on the suction side: DN 200, PN 10
Pipe connection on the discharge side: DN 100, PN 10
Connection venting: Ø 75
Ordering information
Brand: Wilo
Product description: EMUport CORE 60.2-16/540
Net weight, approx.: 602 kg
Article number: 2554548
