Ebara - GSS 32-200 /11 - Part Number: GSS 32-200 /11

Ebara – GSS 32-200 /11 – Part Number: GSS 32-200 /11

GSS 32-200 /11

SKU: GSS 32-200 /11 Categories:
Download Data Sheet

Part Number: GSS 32-200 /11

1 Pump type End Suction Volute Pump Fluid Water
2 Number of pumps / Reserve 1 / 0 Liquid temperature °C 20
3 Flow m³/h Kin. viscosity mm²/s 1.005
4 Head m Vapour pressure bar 0.0234
5 Geodetic head m PH value
6 Inlet pressure (pin) bar 0 Density kg/m³ 998.3
7 Available system NPSH Solids Weight % 0
8 Ambient temperature °C 20

Booster Set
9 Pump Name GSS 32-200.1 /7.5 Frequency Hz None 50
10 Design End Suction Volute Pump Installation type None with ISO base, motor
11 Manufacturer EBARA ImpellernDiameter Max. mm 207
12 Speed rpm 2900 None Designed mm 207
13 No. of Stage 1 None Min. mm 172
14 Connection Suction side EN PN16 Flow Operating m³/h
15 Connection Discharge side EN PN16 None Max- m³/h 30
16 Max Working Pressure bar 16 None Min- m³/h 3.96
17 Shut-off head bar 5.37 Head Operating m
18 Total weight kg See the table of “Dimensions”. None – (Qmax.) m 39.0
19 Shaft power kW None – (Qmin.) m 54.7
20 Max. Shaft Power at max. impeller kW None 5.66
21 Required pump NPSH m Efficiency % None

Materials
22 Casing SCS13
23 Impeller SCS13
24 Shaft SUS329J3L/S35C
25 Case wear ring SUS316
26 O-ring FKM
27 Mechanical Seal SiC/Carbon/FKM

Motor
28 Manufacturer EBARA Standard Insulation class F
29 Type 132S_7.5_3_380 Phases 3~
30 Specific design TEFC/B3/AESV1S / 50 Hz / Pole pairs 1 Frame size 132S
31 Rated power kW 7.5 Weight kg 65
32 Number of poles 2 Electric voltage V 380
33 Speed rpm 2895 Electric current A 16.2
34 Degree of protection IP55
35
