Multistage, horizontal centrifugal pump in glanded pump design, self-priming, with directly flanged motor. The shaft bushing is sealed by a maintenance-free, force-flushed mechanical seal.
For pumping and pressure boosting of drinking water or slightly muddy water in the residential, agricultural and other areas.
Water supply from wells, rainwater storage tanks for irrigation, sprinkling, pressure boosting etc.
2-pole single-phase motor with threaded cable connection, capacitor in the connection box, motor protection switch with automatic reactivation.
Scope of delivery
– Pump
– Two plastic connectors with seals for manually connecting to the inlet pipe
– A quick electrical connection
– Installation and operating instructions
Accessories
– HiControl 1
– HiControl 1-EK
– Float switch WA 65
– Float switch WAEK 65
– Float switch WAO 65
– Float switch WAO EK 65
– Dry-running protection for single-phase motors (G11/4)
Operating Data
Fluid media: Water 100 %
Fluid temperature: 20.00 °C
Fluid concentration: 100.00 %
Requested flow:
Requested head:
Max. delivery head: 29.98 m
Product data
Maximum operating pressure: 8 bar
Min. fluid temperature: 5 °C
Max. fluid temperature: 35 °C
Max. ambient temperature: 50 °C
Motor data
Mains connection: 1~230V/50 Hz
Voltage tolerance: +10/-15 %
Rated power: 0.4 kW
Rated current: 2.7 A
Rated speed: 2,900 1/min
Insulation class: F
Protection class: X4
Materials
Pump housing: PA6T/6I-GF40
Impeller: PPE/PS-GF30
Shaft: 1.4021
Shaft seal: BVPFF
Gasket material: EPDM
Stage chamber material: PPE/PS-GF30
Installation dimensions
Pipe connection on the suction side: G 1, PN 8
Pipe connection on the discharge side: G 1, PN 8
Ordering information
Brand: Wilo
Product description: HiMulti 3-23 P/1/5/230
Net weight, approx.: 7.8 kg
Article number: 4244147
