| Product name | Hydro EN 125-315 /316 S1JS ASD-U1 |
| Product No | 99843926 |
| EAN number | 5713835083746 |
| Rated flow | 435 m³/h |
| Rated head | 123.6 m |
| Electric cooling flow | 9 m³/h |
| Nominal impeller diameter | 315 mm |
| Approvals | CE |
| Fire standard | EN 12845 |
| Number of pumps | 2 |
| Main pump type | NKF 125-315/316 |
| Number of electrical driven pumps | 1 |
| Jockey pump type | CR3-23 |
| Number of Jockey pumps | 1 |
| Pump housing | Cast iron |
| Impeller | Bronze |
| Manifold | Galvanized steel |
| Range of ambient temperature | 5 .. 40 °C |
| Relative humidity | 50 % |
| Maximum operating pressure | 16 bar |
| Type of inlet connection | DIN |
| Type of outlet connection | DIN |
| Size of inlet connection | DN 150 |
| Size of outlet connection | DN 200 |
| Type of inlet connection for Jockey pump | Rp |
| Size of inlet connection for Jockey pump | 1 1/4 inch |
| Earth connection | PE |
| Elevation above sea level | 1000 m |
| Pumped liquid | Water |
| Liquid temperature range | 0 .. 40 °C |
| Selected liquid temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Motor standard | IEC |
| Driver type | Electric Motor |
| Mains supply for electrical motor | 3 x 400 V |
| Rated power – P2 | 200 kW |
| Mains frequency | 50 Hz |
| Rated current | 330 A |
| Starting current | 720 % |
| Motor nominal speed (w/o slip) | 2990 rpm |
| Number of poles | 2 |
| Method of start | Star-delta (YD) |
| Enclosure class (IEC 34-5) | IP54 |
| Motor standard for Jockey pump | IEC |
| Mains supply for jockey motor | 3 x 400 V |
| Rated power – P2 for Jockey pump | 2.2 kW |
| Rated current for Jockey pump | 4.6 A |
| Number of poles for Jockey pump | 2 |
| Method of start for Jockey pump | Direct-on-line (DOL) |
| Net weight | 2490 kg |
| Gross weight | 2860 kg |
Hydro EN 125-315 /316 S1JS ASD-U1
