| Product name | Hydro EN 40-250 /210 S1JS ADL-U1 |
| Product No | 99843867 |
| EAN number | 5713835083142 |
| Rated flow | 63.5 m³/h |
| Rated head | 43.1 m |
| Electric cooling flow | 1 m³/h |
| Nominal impeller diameter | 250 mm |
| Approvals | CE |
| Fire standard | EN 12845 |
| Number of pumps | 2 |
| Main pump type | NKF 40-250/210 |
| Number of electrical driven pumps | 1 |
| Jockey pump type | CM3-10 |
| Number of Jockey pumps | 1 |
| Pump housing | Cast iron |
| Impeller | Bronze |
| Manifold | Galvanized steel |
| Range of ambient temperature | 5 .. 40 °C |
| Relative humidity | 50 % |
| Maximum operating pressure | 16 bar |
| Type of inlet connection | DIN |
| Type of outlet connection | DIN |
| Size of inlet connection | DN 65 |
| Size of outlet connection | DN 65 |
| Type of inlet connection for Jockey pump | Rp |
| Size of inlet connection for Jockey pump | 1 1/4 inch |
| Earth connection | PE |
| Elevation above sea level | 1000 m |
| Pumped liquid | Water |
| Liquid temperature range | 0 .. 40 °C |
| Selected liquid temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Motor standard | IEC |
| Driver type | Electric Motor |
| Mains supply for electrical motor | 3 x 400 V |
| Rated power – P2 | 11 kW |
| Mains frequency | 50 Hz |
| Rated current | 20 A |
| Starting current | 760 % |
| Motor nominal speed (w/o slip) | 2980 rpm |
| Number of poles | 2 |
| Method of start | Direct-on-line (DOL) |
| Enclosure class (IEC 34-5) | IP54 |
| Motor standard for Jockey pump | IEC |
| Mains supply for jockey motor | 3 x 400 V |
| Rated power – P2 for Jockey pump | 1.5 kW |
| Rated current for Jockey pump | 3.3 A |
| Number of poles for Jockey pump | 2 |
| Method of start for Jockey pump | Direct-on-line (DOL) |
| Net weight | 401 kg |
| Gross weight | 461 kg |
Hydro EN 40-250 /210 S1JS ADL-U1
