Hydro MPC-E 6 CRE32-5

SKU: 93068903 Categories: Pumps , Hydro MPC-E

Product name	Hydro MPC-E 6 CRE32-5
Product No	93068903
EAN number	5715123507330
Rated flow	36 m³/h
Rated head	110 m
Max. head	141 m
Main pump name	CRE32-5
Main pump No	92962186
Number of pumps	6
Manifolds	EN/DIN 1.4301/ AISI 304
Range of ambient temperature	5 .. 45 °C
Maximum operating pressure	16 bar
Manifold outlet	DN150
Pressure rating	PN 16
Earth connection	PE
System design	D
Pumped liquid	Water
Liquid temperature range	0 .. 60 °C
Selected liquid temperature	20 °C
Density	998.2 kg/m³
Power (P2) main pump	15 kW
Mains frequency	50 / 60 Hz
Rated voltage	3 x 380-415 V
Start. method	Variable frequency drives
Enclosure class (IEC 34-5)	IP54
Dry running protection, mechanical	NONE
Net weight	1540 kg
Gross weight	1850 kg
Sales region	Italy
