| Product name | MTB 65-200/183 A-F-A-BQQV |
| Product No | 98501636 |
| EAN number | 5711496196560 |
| Rated flow | 60 m³/h |
| Rated head | 32 m |
| Actual impeller diameter | 183 mm |
| Primary shaft seal | BQQV |
| Curve tolerance | ISO9906:2012 3B |
| Pump version | A |
| Pump housing | Cast iron |
| Impeller | Cast iron |
| Material code | A |
| Maximum ambient temperature | 60 °C |
| Maximum operating pressure | 16 bar |
| Flange standard | DIN |
| Pump inlet | DN 80 |
| Pump outlet | DN 65 |
| Pressure rating | PN 16 |
| Connect code | F |
| Pumped liquid | Water |
| Liquid temperature range | 0 .. 90 °C |
| Selected liquid temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Motor type | 160MB |
| Rated power – P2 | 11 kW |
| Mains frequency | 50 Hz |
| Rated voltage | 3 x 220-240D/380-415Y V |
| Rated current | 36,0-34,5/20,8-19,8 A |
| Starting current | 660-780 % |
| Cos phi – power factor | 0.88-0.84 |
| Rated speed | 2940-2950 rpm |
| IE Efficiency class | IE3 |
| Motor efficiency at full load | 91.2 % |
| Motor efficiency at 3/4 load | 91.8 % |
| Motor efficiency at 1/2 load | 91.3-91.2 % |
| Number of poles | 2 |
| Enclosure class (IEC 34-5) | 55 Dust/Jetting |
| Insulation class (IEC 85) | F |
| Built-in motor protection | PTC |
| Motor No | 87420001 |
| Motor range | Standard |
| Net weight | 149 kg |
| Gross weight | 180 kg |
| Shipping volume | 0.724 m³ |
MTB 65-200/183 A-F-A-BQQV
