Operating Data
Fluid media: Water 100 %
Fluid temperature: 20.00 °C
Fluid concentration: 100.00 %
Requested flow:
Requested head:
Product data
Min. fluid temperature: -15 °C
Max. fluid temperature: 120 °C
Max. ambient temperature: 50 °C
Maximum operating pressure: 16 bar
Maximum inlet pressure: 1,000 kPa
Minimum efficiency index (MEI):
Motor data
Mains connection: 3~460V/60 Hz
Voltage tolerance: +-6 %
Rated power: 30 kW
Motor efficiency class: IE3
Rated current: 45.8 A
Rated speed: 3,560 1/min
Power factor: 0.9
Motor efficiency 50%:
Motor efficiency 75%:
Motor efficiency 100%:
Insulation class: F
Protection class: IP55
Materials
Pump housing: 5.1301/EN-GJL-250
Impeller: 1.4301
Shaft: 1.4057
Shaft seal: U3BE3GG
Gasket material: EPDM
Stage chamber material:
Installation dimensions
Pipe connection on the suction side: DN 100, PN 16
Pipe connection on the discharge side: DN 100, PN 16
Ordering information
Brand: Wilo
Product description: MVI 9502/1-3/16/E/3-460-60-2
Net weight, approx.: 286 kg
Article number: 4082642
