| Product name | NBE 015-070/6.93 ASAG6S2ESBQQEICA |
| Product No | 93185349 |
| EAN number | 5715468964980 |
| Pump speed on which pump data are based | 2200 rpm |
| Rated flow | 37.38 m³/h |
| Rated head | 16.9 m |
| Actual impeller diameter | 176 mm |
| Shaft seal arrangement | Single |
| Primary shaft seal | BQQE |
| Code for shaft seal | BQQE |
| Curve tolerance | 2B HI 14.6:2016 |
| Pump version | A |
| Pump housing | Cast iron |
| Impeller | Stainless steel |
| Internal pump house coating | No coating |
| Material code | S2 |
| Code for rubber | E |
| Shaft | Stainless steel |
| Maximum ambient temperature | 50 °C |
| Maximum operating pressure | 12 bar |
| Pipe connection standard | ASME B16.1 |
| Size of inlet connection | DN 65 |
| Size of outlet connection | DN 40 |
| Pressure rating for connection | Class 125 |
| Support block (Yes/No) | N |
| Connect code | G |
| Pumped liquid | Water |
| Liquid temperature range | -25 .. 120 °C |
| Selected liquid temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Rated power – P2 | 2.2 kW |
| Mains frequency | 50 / 60 Hz |
| Rated voltage | 3 x 440-480 V |
| Rated current | 3.90-3.70 A |
| Cos phi – power factor | 0.87-0.83 |
| Rated speed | 180-2200 rpm |
| IE Efficiency class | IE5 |
| Motor efficiency at full load | 91.1 % |
| Number of poles | 4 |
| Enclosure class (IEC 34-5) | IP55 |
| Insulation class (IEC 85) | F |
| Built-in motor protection | ELEC |
| Motor No | 99198279 |
| Mount. design. acc. IEC 34-7 | NEMA type C / foot |
| Bearing insulation type N-end | Steel Bearing |
| Control panel | HMI300 – Advanced |
| Function Module | FM300 – Advanced |
| Frequency converter | Built-in |
| Pressure sensor | Y |
| DOE Pump Energy Index VL | 0.43 |
| Net weight | 63 kg |
| Gross weight | 63.3 kg |
| Shipping volume | 0.119 m³ |
NBE 015-070/6.93 ASAG6S2ESBQQEICA
