Submersible pump for stationary and portable wet well installation in intermittent operation.
For pumping in commercial areas of:
– Sewage not containing faeces
– Wastewater (with small amounts of sand and gravel)
– Wastewater, slightly acidic with a pH value > 4.5
Sewage pumping according to (DIN) EN 12050
The pumps meet the requirements of EN 12050-2.
Wastewater pump with open multi-channel impeller and vertical threaded connection. Hydraulics housing and impeller made of copolymer. Surface-cooled 1~ motor with integrated operating capacitor and self-switching thermal motor monitoring. Oil-filled sealing chamber with double sealing. Stainless steel motor housing and mounted vertical float switch. Detachable connection cable with fitted shockproof plug.
Operating Data
Fluid media: Water 100 %
Fluid temperature: 20.00 °C
Requested flow:
Requested head:
Max. delivery head: 20.68 m
Product data
Hydraulics type: Open multi-channel impeller
Free ball passage of the hydraulics: 10 mm
Maximum operating pressure: 2.27 bar
Max. immersion depth: 7 m
Fluid temperature: 3…40 °C
Max. fluid temperature: 40 °C
Motor data
Mains connection: 1~230V/50 Hz
Voltage tolerance: +-10 %
Power factor: 0.98
Rated power: 1.5 kW
Power consumption: 2.1 kW
Rated current: 9.3 A
Starting current: 29 A
Activation type: Direct On Line (DOL)
Rated speed: 2,852 1/min
Max. switching frequency: 60 1/h
Insulation class: F
Protection class: IP68
Operating mode (immersed): S1
Operating mode (non-immersed): S2-15 min, S3-10%
Cable
Connection cable length: 10 m
Cable type: H07RN-F
Cable cross-section: 3G1
Mains plug: CEE 7/7 (Schuko)
Type of connection cable: Detachable
Equipment/function
Float switch: Yes
Explosion protection type: –
Motor protection: Bimetall
Materials
Pump housing: PP-GF30
Impeller: PP-GF30
Shaft: 1.4401
Sealing on pump side: QQPGG
Sealing on motor side: BXPFF
Gasket material: NBR
Motor housing: 1.4301
Installation dimensions
Pipe connection on the suction side: , –
Pipe connection on the discharge side: G 2, PN 10
Ordering information
Brand: Wilo
Product description: Padus UNI-M05/M15-523/VA
Net weight, approx.: 19 kg
Article number: 6096630
