| Product name | S1.100.125.500.4.62M.S.367.G.N.D.513GPA |
| Product No | 96810471 |
| EAN number | 5700310981819 |
| Maximum flow | 135 l/s |
| Maximum head | 55 m |
| Actual impeller diameter | 367 mm |
| Type of impeller | 1-CHANNEL |
| Max. Particle | 100 mm |
| Curve tolerance | ISO9906:2012 3B |
| Cooling jacket (Yes/No) | N |
| Lifting height class | M |
| Pump housing | Cast iron |
| Impeller | Cast iron |
| Motor | Cast iron |
| Shaft seal | SIC |
| Secondary shaft seal | SIC-CARBON |
| Range of ambient temperature | 0 .. 40 °C |
| Type of connection | DIN |
| Size of outlet connection | DN 125 |
| Pressure rating for connection | PN 10 |
| Maximum installation depth | 20 m |
| Inst dry/wet | S |
| Auto coupling | 96782145 |
| Liquid temperature range | 0 .. 40 °C |
| Selected liquid temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Frame size | 62 |
| Power input P1 | 56 kW |
| Rated power – P2 | 50 kW |
| Mains frequency | 50 Hz |
| Rated voltage | 3 x 415 V |
| Voltage tolerance | +10/-10 % |
| Max starts per hour | 15 |
| Rated current | 98/ A |
| Maximum current consumption | 98 A |
| Starting current | 508 A |
| Rated current at no load | 42 A |
| Rated speed | 1470 rpm |
| Motor efficiency at full load | 89 % |
| Motor efficiency at 3/4 load | 90 % |
| Motor efficiency at 1/2 load | 89 % |
| Number of poles | 4 |
| Method of start | Y/D |
| Enclosure class (IEC 34-5) | IP68 |
| Insulation class (IEC 85) | F |
| Explosion proof | no |
| Ex-protection standard | N THERM |
| Power cable type | H07RN-F AT |
| Length of power cable | 15 m |
| Cable description | 2X4X16MM2+1X7X1,5MM2 |
| Cable resistance | 1.21 mOhm/m |
| Winding resistance | 0.136 Ohm |
| Cos phi 1/1 | 0.80 |
| Cos phi 1/2 | 0.63 |
| Cos phi 3/4 | 0.74 |
| Moisture sensor | with moisture sensors |
| Water-in-oil sensor | without water-in-oil sensor |
| Net weight | 620 kg |
| Gross weight | 730 kg |
| Sales region | GPA |
S1.100.125.500.4.62M.S.367.G.N.D.513GPA
