Sewage pump in block design with fitted standard motor for the stationary dry well installation in continuous operation. For pumping in commercial areas of:
– Untreated sewage
– Sewage containing faeces
– Wastewater
Hydraulic system with axial suction ports, radial discharge ports and bearing brackets as a single unit. The connections are configured as flange connections. Bearing bracket with sealing and leakage chamber for admission of fluid ingress via the seal. Fluid-side and motor-side sealing via a bidirectional mechanical seal. The sealing chamber is filled with medical white oil, the leakage chamber is empty and shut up to the motor. IEC standard motor in B5 design as three-phase motor with motor efficiency class IE3.
Operating Data
Fluid media: Water 100 %
Fluid temperature: 20.00 °C
Requested flow:
Requested head:
Max. delivery head: 22.22 m
Product data
Hydraulics type: Vortex impeller
Free ball passage of the hydraulics: 65 mm
Maximum operating pressure: 2.4 bar
Fluid temperature: 3…70 °C
Ambient temperature: -20…40 °C
Motor data
Motor design: TEFC
Motor efficiency class: IE3
Mains connection: 3~400V/50 Hz
Voltage tolerance: +-10 %
Power factor: 0.86
Rated power: 7.5 kW
Power consumption: 8.4 kW
Rated current: 14.2 A
Starting current: 40 A
Activation type: Star-Delta (YΔ)
Number of poles: 2
Rated speed: 2,936 1/min
Max. switching frequency: 10 1/h
Insulation class: F
Protection class: IP55
Equipment/function
Motor protection: 3 PTC-150°
Sealing chamber, leakage detection: No
Leakage chamber, leakage detection: No
Materials
Pump housing: 5.1301/EN-GJL-250
Impeller: 5.1301/EN-GJL-250
Shaft: 1.4021
Shaft seal: Q1Q1VGG
Gasket material: FKM
Motor housing: 5.1301/EN-GJL-250
Installation dimensions
Pipe connection on the suction side: DN 65, PN 10
Pipe connection on the discharge side: DN 65, PN 10
Ordering information
Brand: Wilo
Product description: Rexa BLOC-V06.22-140DAH132S2
Net weight, approx.: 110 kg
Article number: 6098529
