Fully submersible grinder pump for stationary and portable wet well installation in intermittent operation.
For the pumping in domestic areas of:
– Sewage containing faeces
– Wastewater (with small amounts of sand)
Sewage pumping according to (DIN) EN 12050
The pumps meet the requirements of EN 12050-1.
Sewage pump with radial macerator with double shear effect. Horizontal discharge port with flange and oval connection. Hydraulics housing and impeller made of grey cast iron; macerator made of hardened cutting steel. Surface-cooled 3~ motor with thermal motor monitoring. Oil-filled sealing chamber with two mechanical seals. Stainless steel motor housing. Detachable connection cable with bare cable ends.
Operating Data
Fluid media: Water 100 %
Fluid temperature: 20.00 °C
Requested flow:
Requested head:
Max. delivery head: 20.50 m
Product data
Hydraulics type: Two-channel impeller with macerator
Maximum operating pressure: 2.25 bar
Max. immersion depth: 7 m
Fluid temperature: 3…40 °C
Motor data
Motor design: Submersible motor – surface-cooled
Mains connection: 3~400V/50 Hz
Voltage tolerance: +-10 %
Power factor: 0.78
Rated power: 0.75 kW
Power consumption: 1.03 kW
Rated current: 1.9 A
Starting current: 10.1 A
Activation type: Direct On Line (DOL)
Number of poles: 2
Rated speed: 2,840 1/min
Max. switching frequency: 60 1/h
Insulation class: F
Protection class: IP68
Operating mode (immersed): S1
Operating mode (non-immersed): S2-15 min, S3-10%
Cable
Connection cable length: 10 m
Cable type: H07RN-F
Cable cross-section: 6G1
Mains plug: No
Type of connection cable: Detachable
Equipment/function
Float switch: No
Macerator: Yes
Explosion protection type: –
Motor protection: Bimetall
Motor, leakage detection: No
Sealing chamber, leakage detection: No
Leakage chamber, leakage detection: No
Materials
Pump housing: 5.1301/EN-GJL-250
Macerator:
Impeller: 5.1301/EN-GJL-250
Shaft: 1.4401
Sealing on pump side: QQPGG
Sealing on motor side: NBR
Gasket material: NBR
Motor housing: 1.4301
Installation dimensions
Pipe connection on the suction side: , –
Pipe connection on the discharge side: DN 32/40, PN 6/10
Ordering information
Brand: Wilo
Product description: Rexa MINI3-S03/T008-540/O
Net weight, approx.: 22 kg
Article number: 6093592
