Part Number: SWT 300 M
| 1 | Pump type | CENTRIFUGAL PUMPS FOR POOLS | Fluid | Water |
| 2 | Number of pumps / Reserve | 1 / 0 | Liquid temperature °C | 20 |
| 3 | Flow m³/h | Kin. viscosity mm²/s | 1.005 | |
| 4 | Head m | Vapour pressure bar | 0.0234 | |
| 5 | Geodetic head m | PH value | ||
| 6 | Inlet pressure (pin) bar | 0 | Density kg/m³ | 998.3 |
| 7 | Available system NPSH | Solids Weight % | 0 | |
| 8 | Ambient temperature °C | 20 |
| Booster Set | |||||
|---|---|---|---|---|---|
| 9 | Pump name | SWT 300 M | Frequency Hz | None | 50 |
| 10 | Design | CENTRIFUGAL PUMPS FOR POOLS | Installation type | None | STANDARD |
| 11 | Manufacturer | EBARA | ImpellernDiameter | Max. mm | 0 |
| 12 | Speed rpm | 2900 | None | Designed mm | |
| 13 | No. of Stage | 1 | None | Min. mm | 0 |
| 14 | Connection Suction side | Female thread 2″ (Kit PVC 6 3 included) | Flow | Operating m³/h | |
| 15 | Connection Discharge side | Female thread 2″ (Kit PVC 6 3 included) | None | Max- m³/h | 32 |
| 16 | Max Working Pressure bar | None | Min- m³/h | 0.96 | |
| 17 | Shut-off head bar | 2.30 | Head | Operating m | |
| 18 | Total weight kg | See the table of “Dimensions”. | None | – (Qmax.) m | 5.3 |
| 19 | Shaft power kW | None | – (Qmin.) m | 23.7 | |
| 20 | Max. fluid temperature °C | 40 | Max. Shaft Power at max. impeller kW | None | 2.21 |
| 21 | Required pump NPSH m | Efficiency % | None | ||
| Materials | ||||
|---|---|---|---|---|
| 22 | Pump body | Polypropylene reinforced with glass fibre | Opening key | Polypropylene reinforced with glass fibre |
| 23 | Pump Body Lid | Polypropylene reinforced with glass fibre | ||
| 24 | Diffuser | Polypropylene reinforced with glass fibre | ||
| 25 | Impeller | Noryl | ||
| 26 | Mechanicals seal | Carbon / Ceramic / Stainless Steel AISI 316 | ||
| 27 | Shaft | Stainless Steel AISI 316 | ||
| Motor | ||||
|---|---|---|---|---|
| 28 | Manufacturer | EPE Standard | Insulation class | F |
| 29 | Type | SWT 300 M_230_Single Phase | Phases | 1~ |
| 30 | Specific design | – / 50 Hz / Pole pairs 1 | Frame size | |
| 31 | Rated power kW | 2.2 | Weight kg | |
| 32 | Number of poles | 2 | Electric voltage V | 230 |
| 33 | Speed rpm | 2900 | Electric current A | 12.2 |
| 34 | Degree of protection | IP 55 | ||
