| Product name | UPS 40-80 FN 250 |
| Product No | 95906774 |
| EAN number | 5700318352154 |
| Speed no | 3 |
| Rated flow | 5.13 m³/h |
| Rated head | 5.19 m |
| Maximum head | 80 dm |
| TF class | 110 |
| Approvals | CE,WEEE,UKCA |
| Pump housing | Stainless steel |
| Impeller | Composite |
| Range of ambient temperature | 0 .. 40 °C |
| Amb. max at 80 dgr C liquid | 40 °C |
| Maximum operating pressure | 10 bar |
| Pipe connection standard | EN 1092-2 |
| Type of connection | DIN |
| Size of connection | DN 40 |
| Pressure rating for connection | PN 10 |
| Port-to-port length | 250 mm |
| Pumped liquid | Water |
| Liquid temperature range | -25 .. 110 °C |
| Selected liquid temperature | 60 °C |
| Density | 983.2 kg/m³ |
| Power input in speed 1 | 140 W |
| Power input in speed 2 | 213 W |
| Max. power input | 230 W |
| Mains frequency | 50 Hz |
| Rated voltage | 1 x 230 V |
| Current in speed 1 | 0.66 A |
| Current in speed 2 | 0.97 A |
| Current in speed 3 | 1.01 A |
| Capacitor size – run | 3.5 µF |
| Enclosure class (IEC 34-5) | X2D |
| Insulation class (IEC 85) | F |
| Ex-protection standard | CONTACT |
| Thermal protec | internal |
| Terminal box position | 9H |
| Net weight | 8.18 kg |
| Gross weight | 8.5 kg |
| Shipping volume | 0.011 m³ |
UPS 40-80 FN 250
