Specified Performance
Permeate Flow: 9,000 gpd (34.1 m3/d)
Salt Rejection: 99.8% (99.7% minimum)
Test Conditions: 32000 ppm NaCl solution
800 psig (5.5 MPa) Applied Pressure
77 F (25 C) Operating Temperature
10% Permeate Recovery
6.5 – 7.0 pH Range
Product Use and Restrictions
Maximum Applied Pressure: 1200 psig (8.27 MPa)
Maximum Chlorine Concentration: < 0.1 ppm
Maximum Operating Temperature: 113 F (45 C)
pH Range, Continuous (Cleaning): 2-11 (1-13)
Maximum Feedwater Turbidity: 1.0 NTU
Maximum Feedwater SDI (15 mins): 5.0
Maximum Feed Flow: 85 gpm (19.3 m3/h)
Minimum Brine Flow: 12 gpm (2.7 m3/h)
Maximum Pressure Drop for Each Element: 15 psi (0.10 MPa)
