The AM series features extremely powerful 200W amalgam lamp. This series is unique by
the fact that you can handle a high flow with a small number of lamps. Thanks to its unique
L-shape one can install the AM both horizontally and vertically. These are ideal for private water,
industrial, beverage and food industries.
ON DEMAND
• 4-20 mA
• Audio alarm
AM Series
FLOW RATE: From 20 to 160 m3/h
LAMPS: Low-pressure amalgam 200W
LAMP LIFE: 14.000 hrs
UV CHAMBER MATERIAL: Stainless steel 304 or 316L
HYDRAULIC CONNECTIONS: From 2” 1/2 to DN150
MAX PRESSURE: 10 bar
SYSTEM CONFIGURATION: Vertical – horizontal / L
WATER QUALITY: UVT 80-99% 1cm
This series of UV systems has an L-shaped configuration, which, in addition to being highly efficient, allows for easy installation both horizontally and vertically. The amalgam lamp, on the other hand, helps reduce maintenance and intervention costs.
ELECTRICAL PANEL
MODEL: RACK LCD – TC
DISPLAY: LCD – TOUCH SCREEN
IP PROTECTION: IP 54 (more on request)
LAMP POWER REGULATION: optional
PANEL MATERIAL: painted steel
POWER SUPPLY: 230V 50-60 Hz (more on request)
