Name: Ebara - 2GP CDA 4.00 - Part Number: 2GP CDA 4.00
Brand: Waterials
SKU: 2GP CDA 4.00
Availability: InStock

1	Pump type	Booster Set	Fluid	Water
2	Number of pumps	2	Liquid temperature °C	20
3	Flow m³/h		Kin. viscosity cSt	1.005
4	Head m		Vapour pressure kPa	2.34
5	Geodetic head m		PH value
6	Inlet pressure kPa	0	Density kg/m³	998.3
7	Available system NPSH	Ask our technical department.	Solids Weight %	0
8	Ambient temperature °C	20	Installation height m	100

Booster Set
9	Booster set name	2GP CDA 4.00	Frequency Hz	None	50
10	Design	Booster Set		None
11	Manufacturer	EBARA	Impeller Dia.	Max. mm	167
12	Speed rpm	2850	None	Designed mm	167
13	No. of Stage	2	None	Min. mm	167
14	Connection Suction side	G 2 1/2 PN10	Flow	Operating m³/h
15	Connection Discharge side	G 2 PN10	None	Max- m³/h	11.4
16	Max Working Pressure kPa	1000	None	Min- m³/h	3
17	Shut-off head kPa	685.36	Head	Operating m
18	Total weight kg	See the table of “Dimensions”.	None	– (Qmax.) m	48.1
19	Shaft power kW		None	– (Qmin.) m	67.1
20			Max. Shaft Power at max. impeller kW	None
21	Required NPSH m		Efficiency %	None

Materials
22	Frame	Galvanized steel	Casing cover	Cast iron built-in the motor bracket
23	Manifold	AISI 304	O-ring	EPDM
24	Check valve	Brass / NBR	Shaft	AISI 304
25	Ball valve	Brass / PTFE	Shaft seal	Ceramic/Carbon/NBR
26	Impeller	Brass
27	Casing	Cast iron
