Lowara CEA 706/3 Single-Impeller Centrifugal Pump – Technical Specifications
Product Overview
The Lowara CEA 706/3 is a single-impeller centrifugal electric pump, designed for clean water circulation in residential, commercial, and industrial applications. Fabricated from durable AISI 304 stainless steel, this pump offers high corrosion resistance and dependable performance. Compliant with ISO 9906:2012 – Grade 3B.
Hydraulic Performance
-
Maximum Head (H @ Q = 0): 106 ft
-
Maximum Shaft Power: 0.877 hp
-
Hydraulic Duty Point Flow: 0 US g.p.m.
-
Hydraulic Duty Point Head: 0 ft
Motor Specifications
-
Rated Power (P2): 1.0058 hp
-
Nominal Speed: 3490 rpm
-
Design Speed: 3500 rpm
-
Rated Voltage: 220 V
-
Rated Current: 3.03 A
-
Frequency / Phase: 60 Hz / 3-phase
-
Protection Class: IP55
-
Insulation Class: F
-
Permitted Voltage Tolerance: ±10%
Material Construction
-
Pump Body: AISI 304 Stainless Steel
-
Impeller: AISI 304 Stainless Steel
-
Diffuser: AISI 304 Stainless Steel
-
Seal Housing: AISI 304 Stainless Steel
Mechanical Seal Details
-
Fixed Assembly: Carbon Graphite
-
Rotating Assembly: Ceramic
-
Elastomers: NBR
-
Springs: AISI 316
-
Other Components: AISI 304
Operating Conditions
-
Medium: 100% Pure Water
-
Reference Conditions:
-
Temperature: 39.2°F
-
Density: 62.4 lb/ft³
-
Kinematic Viscosity: 1.69E-5 ft²/s
-
-
Installation Type: Monobloc
Pump Dimensions (inches)
-
A: 2 1/8
-
D: 6 7/8
-
H: 8 13/16
-
H1: 4 7/16
-
H2: 10 5/16
-
L: 16 7/8
-
L1: 3 5/16
-
W: 3
-
Inlet (DNA): Rp 1¼
-
Outlet (DNM): Rp 1
General Information
-
Model: CEA 706/3
-
Weight: 57.319 lb
-
Pump Type: Single-impeller centrifugal electric
