| Operating Data | |
|---|---|
| Operating speed | 1775 rpm Stages 1 Min. inch 10 11/16 |
| Head H(Q=0) | 160 at |
| Flow Max | US g.p.m. 3184.6 |
| Flow Min | US g.p.m. 416.5 |
| Total weight | lb 1,893.3 NPSH 3% ft |
| Materials | |
| Impeller | Cast iron, 0.6020 Single mechanical seal, without shaft sleeve |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 100.58 hp Rated current 141 A |
| Rated voltage | 380 V |
| Degree of protection | IP55 |
