| Operating Data | |
|---|---|
| Operating speed | 1764 rpm Stages 1 Min. inch 7 1/2 |
| Head H(Q=0) | 64 at |
| Flow Max | US g.p.m. 2501.1 |
| Flow Min | US g.p.m. 300.6 |
| Total weight | lb 876.1 NPSH 3% ft |
| Materials | |
| Impeller | Cast Iron, EN 1561 – GJL-200, ASTM Class 30 eMG12 – Ø38mm BQ7EGG-WA |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 24.809 hp Rated current 37.3 A Frame size 110 |
| Rated voltage | 380 V Spacer length inch 3/16 |
| Degree of protection | IP55 Coupling protection GR.COUPLGUARD ES32-190-16 A4 3.9683 lb |
