| Operating Data | |
|---|---|
| Operating speed | 3500 rpm Stages 1 Min. inch 5 11/16 |
| Head H(Q=0) | 200 at |
| Flow Max | US g.p.m. 1461.8 |
| Flow Min | US g.p.m. 318.8 |
| Total weight | lb On demand NPSH 3% ft |
| Materials | |
| Impeller | Cast Iron |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 49.618 hp Rated current 66.5 A Frame size 125 |
| Rated voltage | 380 V Spacer length inch 1/8 |
| Degree of protection | IP55 Coupling protection COUPLGUARD 175x152PNTD 0.72751 lb |
