| Operating Data | |
|---|---|
| Operating speed | 1750 rpm Stages 1 Min. inch 7 3/8 |
| Head H(Q=0) | 57 at |
| Flow Max | US g.p.m. 651.6 |
| Flow Min | US g.p.m. 145.3 |
| Total weight | lb 405.4 NPSH 3% ft |
| Materials | |
| Impeller | Cast Iron |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 7.3756 hp Rated current 11.6 A Frame size 95 |
| Rated voltage | 380 V Spacer length inch 1/8 |
| Degree of protection | IP55 Coupling protection COUPLGUARD 190KS95-16 4571 1.5432 lb |
