| Operating Data | |
|---|---|
| Operating speed | 1465 rpm Stages 1 Min. mm 213 |
| Head H(Q=0) | 18 at |
| Flow Max | m³/h 210 |
| Flow Min | m³/h 23.7 |
| Total weight | kg 153.6 NPSH 3% m |
| Materials | |
| Impeller | Cast Iron, EN 1561 – GJL-200, ASTM Class 30 eMG12 – Ø38mm BQ7EGG-WA |
| Rotating ring | Carbon graphite resin impregnated |
| Stationary ring | SiC, silicon carbide, sintered press.less |
| Springs | CrNiMo – Steel |
| Motor data | |
| Rated power | 7.5 kW Rated current 15.2 A |
| Rated voltage | 400 V |
| Degree of protection | IP55 |
